Width:
48mm
Length:
101mm
Series:
3200
IP Rating:
IP65
Input Type:
0 to 10 V, PT1000, 0 to 20 mA, Type K Thermocouple, 4 to 20 mA, Custom, Linear: 10 to 80 mV
Mount Type:
Panel
Diagnostics:
SSR Open Circuit, SSR Failure, SSR Short Circuit, Heater Diagnostics, Short Circuit, Partial Load Failure, Over Current
Output Type:
Logic, Relay
Panel Depth:
90mm
Control Type:
On-Off
Display Type:
LCD, Single Line
Product Type:
PID Temperature Controller
Digital Comms:
Modbus RTU Master Broadcast (1 Parameter), EIA-2, Modbus RTU Slave, EIA 232, EIA 485
Terminal Type:
Screw
Maximum Voltage:
264V ac
Number of Outputs:
3
Standards/Approvals:
BS EN61010, CE, CCC Exempt, BS EN61326, UL, EN14597 TR, EAC, cUL (file E57766)
Maximum Supply Voltage:
264V ac
Maximum Operating Temperature:
55°C
Minimum Operating Temperature:
0°C
