Coil Voltage:
3V dc
Contact Configuration:
DPDT
Mounting Type:
Surface Mount
Maximum Switching Current AC:
0.3 A
Maximum Switching Current DC:
1 A
Maximum Switching Voltage AC:
125V
Maximum Switching Voltage DC:
110V
Series:
FTR-B3
Maximum Switching Power DC:
30 W
Latching:
No
Length:
10.9mm
Depth:
5.7mm
Height:
9mm
Dimensions:
10 x 5.2 x 7.2mm
Terminal Type:
PCB Pin
Application:
Power
Number of Poles:
2
Switching Current:
1A
Electrical Life:
100000 Operations Cycles
Contact Material:
Au Plated AgPd
Minimum Operating Temperature:
-40°C
Isolation Coil To Contact:
1.5kV rms
Maximum Operating Temperature:
+85°C
Coil Power:
100mW
Operating Temperature Range:
-40 → +85°C
Coil Resistance:
90Ω
Maximum Switching Power AC:
37.5VA
Features:
Compact Slim Body Saves Space, Increased Packaging Density, Sealed Construction allows Automatic Washing.
Life:
100000 (Electrical) cycles, 50000000 (Mechanical) cycles
