PNOZmulti 2 Safe Input/Semiconductor Output Module The PNOZ m EF 8DI4DO expansion module connects to a base unit from the PNOZmulti 2 configurable control system. It has 8 safe inputs and 4 safe semiconductor outputs. Depending on the application, it offers protection up to PLe of EN ISO 138491 and up to SIL CL 3 of EN IEC 62061. Features and Benefits Can be configured in the PNOZmulti Configurator 8 safe inputs 4 safe semiconductor outputs, up to PLe of EN ISO 138491 and up to SIL CL 3 of EN IEC 62061 LED for error messages, diagnostics, supply voltage, output circuits and input circuits Test pulse outputs used to monitor shorts across the inputs Monitoring of shorts between the safety outputs Applications The PNOZ m EF 8DI4DO can connect E-Stop, two-hand button, safety gate limit switch, start button, light beam, scanner, enabling switch, PSEN, operating mode selector switch. Standards EN ISO 13849-1 PLe; EN ISO 13849-1 Cat. 4; EN IEC 62061 SIL CL 3. Approvals CE, cULus Listed, TÜV, BG, CCC. Supplied with Screw terminals. Safety Controller
