Width:
217mm
Height:
88mm
Length:
297mm
Weight:
2.1kg
True RMS:
Yes
Display Type:
Digital
Model Number:
8808A
Power Source:
Mains
Product Type:
Multimeter
Multimeter Type:
Bench
Maximum Frequency:
100kHz
Functions Measured:
AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Diode Test, Frequency, Resistance
AC Current Accuracy:
±0.5 % rdg + 0.12
AC Voltage Accuracy:
±0.9 % rdg + 0.05 % range
DC Current Accuracy:
±0.2 % rdg + 0.01
DC Voltage Accuracy:
±0.015 % rdg + 0.003
Standards/Approvals:
No
AC Current Resolution:
0.1μA ac
AC Voltage Resolution:
1μV ac
DC Current Resolution:
0.001μA dc
DC Voltage Resolution:
1 μV dc
Resistance Resolution:
1mΩ
Safety Category Level:
CAT I, CAT II
Safety Category Voltage:
1000V dc
Maximum Operating Temperature:
50°C
Minimum Operating Temperature:
0°C
Maximum AC Current Measurement:
10A ac
Maximum AC Voltage Measurement:
750V ac
Maximum DC Current Measurement:
10A dc
Maximum DC Voltage Measurement:
1kV dc
Maximum Resistance Measurement:
100mΩ
Resistance Measurement Accuracy:
±1.75 % rdg + 0.004 % range
