Width:
84mm
Height:
46mm
Length:
167mm
Series:
Fluke 117
Weight:
550g
True RMS:
Yes
Battery Life:
400h
Battery Type:
Alkaline
Display Type:
Digital
Model Number:
117
Power Source:
Battery
Product Type:
Multimeter
Multimeter Type:
Digital
Maximum Frequency:
50kHz
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode Test, Frequency, Resistance
AC Current Accuracy:
±1.5 % rdg + 3 Digits
AC Voltage Accuracy:
±1 % rdg + 3 Digits
DC Current Accuracy:
±1 % rdg + 3 Digits
DC Voltage Accuracy:
±0.5 % rdg + 2 Digits
Standards/Approvals:
CE, N10140, TUV, CSAus, UL, VDE
AC Current Resolution:
0.001A ac
AC Voltage Resolution:
0.1mV ac
DC Current Resolution:
0.001A ac
DC Voltage Resolution:
0.1 mV dc
Resistance Resolution:
100mΩ
Safety Category Level:
CAT III
Safety Category Voltage:
600V
Maximum Operating Temperature:
50°C
Minimum Operating Temperature:
-10°C
Maximum AC Current Measurement:
10A ac
Maximum AC Voltage Measurement:
600V ac
Maximum DC Current Measurement:
10A dc
Maximum DC Voltage Measurement:
600V dc
Maximum Resistance Measurement:
40mΩ
Resistance Measurement Accuracy:
±1.5 % rdg + 2 Digits
